MONICS Mini TXM 10+10 dBm Optical Transmitter
Reliable Optical Transmission Solutions for CATV Networks
MONTRONICS ELECTRONICS PVT. LTD. presents the MONICS Mini TXM 10+10 dBm Optical Transmitter, designed for compatible Cable Television (CATV), RF signal distribution, and fiber optic transmission applications. This compact optical transmission unit converts compatible radio frequency (RF) signals into optical signals for distribution through fiber optic infrastructure.
Optical transmitters play an important role in modern cable TV networks by enabling RF signals to travel over optical fiber links. The MONICS Mini TXM series is intended for applications where optical transmission equipment is required to support CATV signal distribution and compatible network configurations.
With a compact aluminium enclosure, optical output connections, and a 12V DC power supply, the unit is suitable for integration into compatible CATV transmission setups. The exact configuration, optical output arrangement, and operating parameters should be confirmed for the selected model before installation.
Key Features of the MONICS Mini TXM Optical Transmitter
1. Optical Signal Transmission
Converts compatible RF input signals into optical signals for transmission over fiber optic links in CATV distribution systems.
2. 10+10 dBm Configuration
The 10+10 dBm model is intended for applications requiring its specified optical output configuration. Confirm the manufacturer's datasheet for the meaning of the dual-output rating and the output power available at each port.
3. 1310 nm Optical Wavelength
The supplied product information identifies 1310 nm as the optical wavelength. This wavelength is commonly used in fiber optic transmission systems and should be matched with compatible network equipment.
4. CATV Frequency Range
The product information lists a frequency range of 47–870 MHz. Verify the supported RF bandwidth for the exact model and ensure compatibility with the connected CATV equipment.
5. Compact Aluminium Housing
The silver aluminium enclosure provides a practical form factor for compatible equipment installations and helps protect internal components during normal operation.
6. 12V DC Power Supply
The supplied specifications indicate a 12V DC power requirement. Always use a compatible power adapter and follow the manufacturer's installation instructions.
7. Optical Connector Compatibility
The required optical connector type depends on the product variant and network setup. Confirm the connector interface and polish type before connecting the transmitter to optical fiber.
Technical Specifications
Parameter
Specification
Brand
MONICS
Product name
Mini TXM Optical Transmitter
Configuration
10+10 dBm
Application
CATV / Cable TV
Optical wavelength
1310 nm
RF frequency range
47–870 MHz, as listed for the supplied model
Power supply
12V DC
Housing material
Aluminium
Optical output
Dual-output configuration indicated; confirm datasheet
Connector type
Confirm exact model
Important: Specifications can vary between the MONICS Mini 10 dBm, Mini TXM 10+10 dBm, and transmitter-with-node models. Confirm the exact product variant before publishing final technical specifications or ordering.
Applications of MONICS Mini Optical Transmitters
The MONICS Mini Optical Transmitter can be considered for compatible applications such as:
Cable Television (CATV) distribution networks
RF signal transmission over optical fiber
Cable operator infrastructure
Fiber-based television distribution systems
Compatible broadband and telecom distribution installations
Optical links between compatible CATV headend and distribution equipment
Residential and commercial cable TV infrastructure
The suitability of the transmitter for a specific application depends on the required RF input level, optical output power, fiber distance, connector type, and compatibility with the receiving equipment.
How an Optical Transmitter Works
An optical transmitter receives an electrical RF signal from compatible equipment and converts it into an optical signal. The optical signal travels through a fiber optic cable to a compatible optical receiver or node, where it is converted back into an electrical signal for further distribution.
A correctly configured optical transmission system can help cable operators distribute signals over fiber infrastructure. Appropriate optical power levels, RF input levels, connectors, and receiving equipment must be selected to achieve the intended network performance.
